Therapeutic Level Dose Meter in Data Collation

Product features 7-inch color LCD screen, touch screen operation full Chinese operation interface, intuitive and easy to operate, can display 20 measurement data at the same time, cost-effective technical parameters, measurement range: high range: 20Gγ low range: 2Gγ repeatability: standard deviation of 10 measurements <0.2 stability: <+ -0.5 zero drift: ≤ +-0.1 leakage: <+-1fA ionization chamber plug: BNC plugs can be connected to ionization chambers produced by manufacturers such as Famer and PTW, and can also be equipped with TNC and M plugs according to user requirements. Ionisation chamber: 0.6cm3 ionization chamber, 0.125cm3 ionization chamber, 3

Product Features

7 inch color LCD screen, touch screen operation

All Chinese operation interface, intuitive and easy to operate

20 measurement data can be displayed simultaneously

High cost performance

Technical parameters

Measuring range: high range: 20Gγ low range: 2Gγ

Repeatability: Standard deviation of 10 measurements <0.2%

Stability:<± 0.5%

Zero drift: ≤ ± 0.1

Leakage:<± 1fA

Ionizing chamber plug: BNC plug can be connected to the ionization chamber produced by manufacturers such as Famer and PTW, and can also be equipped with TNC and M plugs according to user requirements;

Ionation chamber: optional 0.6cm3 ionization chamber, 0.125cm3 ionization chamber, 30cm3 ionization chamber, CT ionization chamber, semiconductor ionization chamber, etc.

Function

Measuring the Dose and Dose Rate of Radiotherapy Diagnostic Rays

Temperature and pressure correction is possible

Timing automatic measurement, automatic measurement and manual measurement

Can directly display 20 measurement data and save the measurement data
